Initial Configuration
l The target Bluetooth device should be as close as possible (up to 32.8 ft (10 meters) Line of Sight) to the MX7 Tecton
during the pairing process.
Assumption:The System Administrator has Discovered and Paired targeted Bluetooth devices for the MX7 Tecton. The MX7
Tecton operating system has been upgraded to the revision level required for Bluetooth client operation. An application (or API)
is available that will accept data from serial Bluetooth devices.
Initial Configuration
1. Select Start | Settings | System | Bluetooth or tap the Bluetooth icon at the bottom of the Today panel.
2. Tap the Settings Tab.
3. Change the Computer Friendly Name at the bottom of the Settings display. The Bluetooth MX7 Tecton default name is
determined by the factory installed software version. LXE strongly urges assigning every MX7 Tecton a unique name
(up to 32 characters) before Bluetooth Discovery is initiated.
4. Check or uncheck the MX7 Tecton Bluetooth options on the Settings tab and the Reconnect tab.
5. Tap the OK button to save your changes.
Subsequent Use
Note: Today panel and Bluetooth device Icon states change as Bluetooth devices are discovered, paired, connected and
disconnected. A Today panel Bluetooth icon with a red background indicates Bluetooth is active and not paired with any
device. A device icon with a red background indicates a disconnected paired device.
1. Tap the Bluetooth icon at the bottom of the Today panel to open the Bluetooth LXEZ Pairing application.
2. Tap the Bluetooth Devices tab.
3. Tap the Discover button. When the Bluetooth module begins searching for in-range Bluetooth devices, the button name
changes to Stop. Tap the Stop button to cancel the Discover function at any time.
4. The discovered devices are listed in the Bluetooth Devices window.
5. Highlight a Bluetooth device in the Discovered window and double-tap to open the device properties menu.
6. Tap Pair as Scanner to set up the MX7 Tecton to receive scanner data.
7. Tap Pair as Printer to set up the MX7 Tecton to send data to the printer.
8. Tap Serial Device (when Filtered mode is disabled) to set up the MX7 Tecton to communicate with a Bluetooth serial
device.
9. Tap Disconnect to stop pairing with the device. Once disconnected, tap Clear to remove the device name and data from
the MX7 Tecton Bluetooth Devices list.Select Yes at the "Delete all disconnected devices? Yes / No" dialog box.
10. Upon successful pairing, the selected device may react to indicate a successful connection. The reaction may be an
audio signal from the device, flashing LED on the device, or a dialog box is placed on the MX7 Tecton display.
11. Whenever the MX7 Tecton is turned On, all previously paired, live, Bluetooth devices in the vicinity are paired, one at a
time, with the MX7 Tecton. If the devices cannot connect to the MX7 Tecton before the re-connect timeout time period
expires (default is approximately 20 seconds for each paired device) there is no indication of the continuing disconnect
state if Report Failure to Reconnect is disabled.
E-EQ-MX7WMRG-A [ 73 ] MX7 Tecton™ for Windows Mobile Reference Guide
