Buttons
Notes
l When Strip: Code ID (see Symbology panel) is not enabled, the code ID is sent as part of the barcode data to an appli-
cation.
l When Strip: Code ID (see Symbology panel) is enabled, the entire Code ID string is stripped (i.e. treated as a Code ID).
l UPC/EAN Codes only: The Code ID for supplemental barcodes is not stripped.
l When Enable Code ID is set to AIM, Symbol or HHP, Custom Code IDs appear at the end of the list of standard Code
IDs.
l When Enable Code ID is set to Custom, Custom Code IDs replace the list of standard Code IDs.
l Symbol equipped devices are configured using configuration barcodes, When Enable Code ID is set to Custom, AIM or
Symbol Code IDs must be added to the end of the Custom Code ID. For example, if a Custom Code ID ‘AAA’ is created
to be read in combination with an AIM ID for Code 39 ‘]A1’, the Custom Code ID must be entered with the AIM ID code
first then the Custom Code ID : ]A1AAA.
l When Enable Code ID is set to None, Code IDs are ignored.
l Custom symbologies appear at the end of the list in the Symbology dialog, but will be processed at the beginning of the
list in the scanner driver. This allows custom IDs, based on actual code IDs, to be processed before the Code ID.
l The external scanner operation cannot be controlled by the MX7 Tecton scanner driver; therefore, a ‘good’ beep may be
sounded from the external scanner even if a barcode from an external scanner is rejected because of the configuration
specified. The MX7 Tecton will still generate a ‘bad’ scan beep, to indicate the barcode has been rejected.
Buttons
Symbology Settings
Individually enable or disable a barcode from being scanned, set the minimum and maximum
size barcode to accept, strip Code ID, strip data from the beginning or end of a barcode, or
(based on configurable Barcode Data) add a prefix or suffix to a barcode before transmission.
Ctrl Char Mapping
Define the operations the Wedge performs on control characters (values less than 0x20)
embedded in barcodes.
Custom Identifiers
Defines an identifier that is at the beginning of barcode data which acts as a Code ID. After a
Custom Identifier is defined, Symbology Settings can be defined for the identifier just like
standard Code IDs.
HHP Properties
Set properties for an HHP imager including centering, mode, range, AIM timer and light
behavior.
Note that the HHP Properties button is only present if the MX7 Tecton is equipped with an
HHP imager.
E-EQ-MX7WMRG-A [ 102 ] MX7 Tecton™ for Windows Mobile Reference Guide
