Speaker The speaker supplies audible verification signals normally used by the Window’s CE operating system. The speaker
is located on the front of the MX7 Tecton, above the MX7 Tecton logo. The mobile device emits a Sound Pressure Level
(loudness) of at least 102 dB measured as follows:
l Frequency: 2650 + 100 Hz
l Distance: 10 cm on axis in front of Speaker opening in front of unit.
l Duration : Continuous 2650 Hz tone.
The default is 1 beep for a good scan and 2 beeps for a bad scan.
Volume Control. Volume control is managed by a Windows Mobile Settings panel, an API and the Orange-Scan up/ down
arrow key sequence.
Voice. All Microsoft-supplied audio codecs are included in the OS image. The hardware codecs, the input and output analog
voice circuitry and the system design are designed to support voice applications using a headset connected to the Adapter,
Audio accessory cable and the MX7 Tecton I/O connector.
Card Slot
There is one user-accessible SD Flash card slot, located in the main battery well, and protected by a rubber flap. Program CAB
files, MX7 Tecton utilities, wireless drivers, the registry and registry backup information are stored on the SD Flash card.
Scanner / Imager Port
The MX7 Tecton has one integrated barcode scanner/imager port. Only one scan engine is installed at a time. Scan engines
are not “hot swappable”. The MX7 Tecton may have one of three Symbol laser scan engines:
l Short Range Laser Scanner, 955I
l Low Power Scanner, 955E
l Multi-Range "LORAX" Laser, 1524ER
or a Hand Held Products 2D Area Imager, 5300.
Note: Low Power Scanner, 955E does not support aim mode. Any attempt to adjust the aiming beam using SE955
programming barcodes will fail. The Low Power scanner does not decode Codablock, Code93i, Matrix 2 of 5 or Telepen
symbologies.
The integrated scan engine activates when the Scan button on the front of the MX7 Tecton is depressed or when the trigger on
an installed trigger handle is depressed. A system applet (Start | Settings | System | Data Collection) is available to set
scanner/imager options.
Functionality of the integrated scan engine driver is based on the decoder driver version installed in the MX7 Tecton. Functions
may include audible tones on good scan (at the maximum db supported by the speaker), failed scan, LED indication of a scan
in progress, among other functions. If enabled, a vibration device provides a tactile response on a good scan event.
