Hardware
System Hardware
802.11 a/b/g Wireless Client
The MX7 Tecton has an LXE 802.11 network card that supports diversity with two internal antennas. The CPU board does not
allow hot swapping the network card. WEP, WPA and LEAP are supported.
Central Processing Unit
The CPU is an 806MHz Intel Xscale PXA320 CPU. The operating system is Microsoft® Windows® Mobile® 6.5. The OS
image is stored on an internal SD flash card and is loaded into DRAM for execution. Turbo mode is supported and turned on by
default.
The MX7 Tecton supports the following I/O components of the core logic:
l One SD card slot under the main battery pack.
l One serial port.
l One Digitizer Input port (Touchscreen).
Program CAB files, utilities, wireless drivers, the registry and registry backup information are stored in internal Flash.
E-EQ-MX7WMRG-A [ 10 ] MX7 Tecton™ for Windows Mobile Reference Guide
