Manitowoc GROVE GMK5150L

Malfunctions during crane operation
14.8 Fuses in the crane cab
Operating manual 3 302 709 en 14 - 77
GMK5150L
12.01.2018
s
Designation Amperage (A) Function
F2/1 15 Control unit UB 1 IOL 30
F2/2 15 Control unit UB 2 IOL 30
F2/3 15 Control unit UB 2 IOL 30
F2/4 15 Control unit UB 1 IOL 34
F2/5 15 Control unit UB 2 IOL 34
F2/6 15 Control unit UB 2 IOL 34
F2/7 15 Control unit UB 2 IOL 34
F2/8 – Unassigned
Designation Amperage (A) Function
F3/1 – Unassigned
F3/2 – Unassigned
F3/3 – Unassigned
F3/4 3 Contact switch for cab lighting
F3/5 5
CCS display
F3/6 5 Hand-held control
F3/7 7,5 Comfort seat
1)
F3/8 5 Cigarette lighter
1)
Additional equipment
