Manitowoc GROVE GMK5150L

Malfunctions during crane operation
14.8 Fuses in the crane cab
14 - 78 3 302 709 en Operating manual
GMK5150L
12.01.2018
Designation Amperage (A) Function
F4/1 5 Control unit UE IOL 30, CCM 10, UE SCM
F4/2 5 Reserve
F4/3 3 CraneSTAR system
F4/4 10 Radio
1)
F4/5 – Unassigned
F4/6 3 Central locking system (reserve)
F4/7 – Unassigned
F4/8 3 Rotating beacon
Designation Amperage (A) Function
F5/1 5
Control unit 15 SCM, CCM 10
Control unit UE IOL 30, IOS 22
F5/2 5 Control unit 15 UE IOS 20 and 21
F5/3 3
CCS display
F5/4 3 Control lever
F5/5 5 Control lever supply
F5/6 3 Reserve
F5/7 5 Reserve
F5/8 5 Switch lighting
1)
Additional equipment
