Malfunctions in driving mode
8.5 Emergency operation and breakdown assistance
8 - 34 3 302 709 en Operating manual
GMK5150L
12.01.2018
Removing a
damaged wheel
• Switch off the suspension; à p. 5 - 17.
• Raise the truck crane with the outriggers until the wheel to be changed
just barely leaves the ground.
• Remove the lug nuts (1) to (12) and remove the damaged wheel
• Secure the wheel against falling over if you set it down temporarily.
On the spare
wheel holder
When changing a wheel, you must remove the spare wheel from the spare
wheel holder and mount the damaged wheel on to the spare wheel holder.
You can use a chain hoist or the truck crane to lift the wheel.
• If you lift the wheel with the truck crane, then:
– Support the truck crane.
– Enter and confirm the current rigging mode.
• Lift the spare wheel using only lifting gear with sufficient load bearing
capacity;
à Spare wheel, p. 1 - 10.
G
Risk of accidents due to a wheel falling over
When unscrewing the final lug nuts, the wheel can slip off the hub and fall
toward you. Secure the wheel and step back quickly if the wheel begins to
tip.
G
Danger of overturning if the truck crane is free-standing
Always support the truck crane on outriggers before rotating the super-
structure.
When the tyres are damaged, you may not operate the truck crane in the
Free on wheels working position.
G
Risk of overturning while slewing
Always check before slewing whether slewing is permitted in the truck
crane's current rigging mode (counterweight, outrigger span, working
radius).
Correct the rigging mode if necessary;
à Slewing with rigged counterweight,
p. 12 - 113.
