Malfunctions in driving mode
8.5 Emergency operation and breakdown assistance
Operating manual 3 302 709 en 8 - 35
GMK5150L
12.01.2018
Third brake light
If there is a third brake light, then you have to remove it before removing the
wheel from the spare wheel holder. Before driving on the road, the brake
light must be reattached.
– Removing
• (A) – Remove the nuts (2).
• (B) – Put the brake light (1) into the holder.
• Undo the nuts (2).
– Installation
• (B) – Remove the nuts (2).
• (A) – Fit the brake light (1) onto the
holder (3).
• Secure the brake light with the nuts (2).
Removing a wheel
• Remove the nuts (1).
• Lift the spare wheel off the holder.
• Secure the spare wheel against falling over
if you put it down temporarily.
Mounting a wheel
• Lift the wheel on to the holder.
• Secure the wheel with the nuts (1) and
tighten them to 500 Nm (370 lbf ft).
