Malfunctions in driving mode
8.5 Emergency operation and breakdown assistance
8 - 42 3 302 709 en Operating manual
GMK5150L
12.01.2018
Check valves – switch off continuous
operation
– For the 3rd axle line
• Always switch off the continuous
operation for all valves (1).
– For the 4th axle line
• Always switch off the continuous
operation for all valves (2).
• (A) – Take the nut (3) off of the valve (5).
• (B) – Fit the magnets (4) – pay attention
marking!
• Tighten the nut (3) hand-tight on the
valve (5).
Inserting the fuses
After emergency operation, you must insert the fuses again so that
the 5th axle line can be steered while driving.
• Turn off the ignition.
• Insert the fuses F2/4 and F2/5; à Fuses in the driver's cab, p. 8 - 50.
• Insert the fuse F10; à Fuses in the battery box, p. 8 - 56.
After emergency
operation
• Drive directly to the workshop and have the fault rectified.
The speed may be reduced depending on the extent of the error.
