Manitowoc GROVE GMK5150L User Manual

Overview
1.5 Technical data
Operating manual 3 302 709 en 1 - 19
GMK5150L
12.01.2018
Outrigger
s
Design: 4-point telescoping outrigger
system
Control system: Can be controlled from both
sides on the carrier and individ-
ually from the crane cab
Outrigger span
(standard):
Metre (ft) Per cent
8.030 x 7.600 m (26.3 x 24.9 ft)
8.030 x 6.700 m (26.3 x 22.0 ft)
8.030 x 5.900 m (26.3 x 19.4 ft)
8.030 x 5.100 m (26.3 x 16.7 ft)
8.030 x 2.500 m (26.3 x 8.2 ft)
100%
83%
66%
50%
0%
Outrigger span
(MAXbase):
à Enabled outrigger spans, p. 12 - 36
Outrigger pads: Diameter: 600 mm (23.6 in)
Surface: 2,826 cm
2
(438 in
2
)
Stroke of supporting
cylinders:
600 mm (23.6 in)
Maximum outrigger
pressure:
Front: 64.6 t (142,420 lbs)
Rear: 74.2 t (163,583 lbs)
Inclination indicator: In the crane cab, at the
outrigger
control units.
Outrigger pressure
display
1)
:
In the outriggers, integrated
with a display in the crane cab
and on the
outrigger control
units depending on design.
1)
Additional equipment
