Step 6: Now go to F3 – Jog/Rapid screen and touch the tool to the side of the test piece.

Step 7: Measure the diameter of the test piece and note the value.

WARNING: Do not Jog or move the tool away unit the next step has been completed.

v5.18 - 08 Apr,2021

www.masso.com.au Page 122 of 477
