16.2.9. WABECO 8 Tool Turret
INFORMATION:
This tool changer is only avilable on MASSO-G3 software v4.0 and above.
Setting up the tool changer
Go to
F1-Setup
screen and open
Tool Changer
window.
From the list select Press enter to open
Tool Changer
list and select the
WABECO 8 Tool
Turret
from the list and double click it to open the below settings window.
v5.18 - 08 Apr,2021
www.masso.com.au
Page 443 of 477
442
444
