19.1. Wiring & Setup
WARNING: Power off the machine and electronics when wiring, unplugging or connecting any
connectors or connections.
WARNING: Double check your connections on the DB9 male and DB9 female connectors as
these can be easily mistaken and if connected at the wrong connector can damage the entire
controller.
DB9 (MALE) Connector on the control box
DB9 (FEMALE) Connector on the control box
