MASSO
MASSO Documentation
16.2.2. Linear - Gang Type Setup
Setting up the tool changer
Go to
F1-Setup
screen and open
Tool Changer
window.
From the list select Press enter to open
Tool Changer
list and select the the
Gang Tooling
from the
list.
v5.18 - 08 Apr,2021
www.masso.com.au
Page 427 of 477
426
428
