MASSO
MASSO Documentation
6.6.8. Editing G-Code
INFORMATION:
The Gcode edit function is intended to edit small Gcode files. If your Gcode file is
larger than 1800 characters it will not open in the edit screen.
Press
F2
to goto the
F2 - Program & MDI
screen
Next press
CTRL + E
to open the edit file window
v5.18 - 08 Apr,2021
www.masso.com.au
Page 98 of 477
97
