MASSO
MASSO Documentation
11.3. Axis Servo/Stepper examples
WARNING: Axis Step and Direction signals are differential type signals and the following
precautions must be taken to wire the controller to avoid any electrical damage to the system:
All axis outputs are differential signals with -4 to +4 voltage signals.
Never short-circuit the signals with each other or any other voltage.
All signals must be isolated to other signals and connected directly to the drives
Wiring example
v5.18 - 08 Apr,2021
www.masso.com.au Page 276 of 477
