MASSO
MASSO Documentation
16.1.1. Manual Tool Changer
Setting up manual tool changer
Go to
F1-Setup
screen and open
Tool Changer
window.
From the list select Press enter to open
Tool Changer
list and select the the
Manual Tool Change
from the list.
Setting tool change position
v5.18 - 08 Apr,2021
www.masso.com.au
Page 402 of 477
401
403
