11.24. MASSO Relay Module
MASSO 6 relay module provides optical isolation to high voltage/current signals from MASSO controller.
Multi color LED's for each relay helps easily troubleshoot issues.
Green color LED indicates that a signal is received to switch on the relay and the relay has been
switched on.
Red color LED indicates that a signal to switch on the relay has been received but the relay has
failed and not working.
Each relay can be used to control 5 Amp 28VDC or 5 Amp 240VAC load.
Works with a single 24VDC power supply.
Board dimensions: 95mm (3.74 inch) x 25mm (0.98 inch)
CAUTION: Connecting the power polarity in reverse will damage the relay module.
INFORMATION: Ordering MASSO relay module CLICK HERE
Scan the QR code to watch the MASSO video tutorial on YouTube
Or, Click here to view the video
v5.18 - 08 Apr,2021
www.masso.com.au Page 356 of 477
