11.23. MASSO Optical Encoder
MASSO contactless optical quadrature encoders are based on a non-mechanical design. By not having
any moving parts, the sensors have very high accuracy and very low failure rate. The encoders can be easily
mounted in front of your Lathe’s spindle pulley to provide full quadrature encoder signals for multi pass
threading.
High accuracy with no moving parts.
Easy to mount with no pulley or timing belts required.
Wide working voltage range 12 to 24VDC.
Easy mounting using M3 screws.
CAUTION: Output signals are 0v for LOW signal and 10v for HIGH signal.
Generate Encoder Disk Label
Simply click the below "Generate Encoder Disk" link to quickly generate the encoder disk label by entering
the pulley Outer Diameter (OD) and Inner Diameter (ID).
Generate Encoder Disk
