8.21. G82 – Drilling Canned Cycle With Dwell
This command is Canned Cycle used for drilling cycle with dwell (pause) at the bottom of hole.
Syntax & Parameters
G82 followed by axis, R, P & F values.
X, Y, Z, A, B Value - specifies the axis you wish to move following the distance to move. The
distance value will be the current machine units in use.
R Value - This is the retract position in the Z axis. This value must be specified.
P Value - This is the dwell (pause) at the bottom of hole. This value is in milliseconds.
F Value - The F value defines the feedrate at which the axis will move at.
Example program
N10 G99 G82 X10 Y10 Z-8 R2 P1000 F100 N20 X20 N30 X30
The first line moves the X & Y axis to 10mm position with retract plane set to 2mm, drilling to Z -8mm
with 1 second dwell at bottom of the hole at 100 mm/minute feedrate and starts drilling.
The second line moves X axis to 20mm position and drill a hole as per the same values.
The third line moves X axis to 30mm position and drill a hole as per the same values.
INFORMATION: Units are defined as either inches or mm depending on your machines setup or
G20 or G21 command in use.
v5.18 - 08 Apr,2021
www.masso.com.au Page 219 of 477
