8.25. G92 – Temporary Work Offset
This command is used set temporary work offset values. The temporary work offsets are used in
combination to the main work offsets G54 to G59.
Syntax & Parameters
G92 followed by axis values.
X, Y, Z, A, B Value - specifies the axis you wish to move following the distance to move. The
distance value will be the current machine units in use.
Example program
N10 G92 X10 Y20
INFORMATION: Units are defined as either inches or mm depending on your machines setup or
G20 or G21 command in use.
INFORMATION: When A G92 work offset is used and a DRO is zeroed the offset value will show
on the DRO instead of 0. Use G92.1 to clear the temporary work offset.
INFORMATION: G92 work offsets can be cancelled by using G92.1 in Gcode or using MDI
v5.18 - 08 Apr,2021
www.masso.com.au Page 223 of 477
