4.4. Machine conversion and Builds
I want to convert a machine to use with MASSO, will it work?
Unless your machine is more than 5 axis or has unusual requirements the answer is generally yes.
We do not know the specifics of your CNC machine, how it is wired and what hardware it has. It is the
responsibility of the person converting the machine to evaluate the existing hardware for
compatibility.
The conversion of a CNC machine needs to take into account many factors.
What drives you have and what connections they have. What Spindle you have and the VFD
connection. What inputs and outputs you need. You need to evaluate each existing item to see if it
conforms to the MASSO standard and replace those items that do not comply. If you are unsure
about a specific piece of equipment please consult the manufacturer's documentation.
Can you supply a wiring diagram for my machine conversion?
MASSO does not offer a machine conversion or machine design service.
We do not provide example wiring diagrams in our documentation. We have example wiring
diagrams for a selection of stepper and servo drive types as well as spindle VFDs.
What equipment do I need to convert my CNC machine?
To establish your requirements you need to do an inventory of what your machine currently has that you can
reuse and what you would like to add.
Example of a basic mill requirements
MASSO, Keyboard, Monitor and mouse or a MASSO Touch
USB Flash drive
Power supply for MASSO
Motor drives using STEP/PULSE and DIRECTION signaling
Power Supply for motor drives
Spindle with VFD or router
Homing sensors/switches, one for each axis
Tool setter for auto tool zero.
Encoder, required for lathe when threading.
Optional
MASSO relay board used for external Estop to motor drives, Tower lights, etc.
Pendant
Encoder for spindle
What can MASSO provide for my machine?
MASSO provides CNC controllers and the following accessories available from our web store
v5.18 - 08 Apr,2021
www.masso.com.au Page 22 of 477
