8.31. G97 – Turn off Constant Surface Speed (CSS)
This command is used to disable Constant Surface Speed (CSS) mode and set to RPM mode in lathe
version.
Syntax & Parameters
G97
Example program
N10 G97
In the above example CSS mode is disabled and the system is set back to RPM mode.
v5.18 - 08 Apr,2021
www.masso.com.au
Page 229 of 477
