18. OEM Logo & Details

Details such as OEM logo, machine model and contact details can be added to the

MASSO startup and F1-Setup screen.

MASSO power up screen with OEM logo

MASSO F1-Setup screen with OEM logo and details

v5.18 - 08 Apr,2021

www.masso.com.au Page 460 of 477
