BLACK – (NO – Normally Open)
WHITE – (NC – Normally Connected)
Mounting
Mount the sensor so that it can't get damaged by the operation of the machine.
It needs to be situated so that when the homing position is reached it is triggered by a metal trigger plate
attached to the machine.
The trigger plate needs to pass between the forks of the sensor.
Homing setup instructions
