Information: If you have a MASSO-G3 or are wiring the X, Y or Z axis on A MASSO-G2 please
CLICK HERE
MASSO G2 Relay wiring example
INFORMATION: Assign the desired function to the Relay output you want to use by double clicking
on the output and selecting the required function from the list.
INFORMATION: All output signals can be easily inverted by selecting the input in the OUTPUTS
list and pressing the space-bar key on the keyboard to invert the input signal. These settings are
automatically saved.
CAUTION: The Maximum current on any relay output must not exceed 400mA or the output will be
damaged.
