INFORMATION: There are multiple Power (Red-colored) and Ground (Black-colored) provided
on the controller and can be used to easily wire drives, sensors and switches.
Some examples:
The Power terminals can be used to provide voltage to sensors or switches for machine homing.
The Ground terminals can be used to wire common ground signals between stepper or servo motor
drives.
CAUTION: Power and Ground terminals provided on the controller are only to be used for very
low current signals. Connecting high current loads can damage the controller beyond repair.
