Wire the sensor inputs and assign to MASSO as below:
Tool Changer - Input 1 for Tool 0 signal input (used to home the turret during machine homing).
Tool Changer - Input 2 for Tool counter signal input.
Tool Changer - Input 3 for Locking pin signal input.
Output Signals
Wire the control outputs and assign to MASSO as below:
1. Tool Changer - Output 1 to rotate turret for tool change rotation.
2. Tool Changer - Output 2 to rotate turret in tool lock direction.
