23 - 1
23
17
CONNECTION TO
ALLEN-BRADLEY PLC
18
CONNECTION TO
SIEMENS PLC
19
MICROCOMPUTER
CONNECTION
20
CONNECTION TO OMRON
TEMPERATURE
CONTROLLER
21
CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
22
CONNECTION TO RKC
TEMPERATURE
CONTROLLER
23
CONNECTION TO
FREQROL SERIES
INVERTER
24
SERVO AMPLIFIER
CONNECTION
INVERTER
CONNECTION
23.1 System Configuration . . . . . . . . . page 23-2
This section describes the equipment and cables needed
when connecting a GOT to a FREQOL SERIES
INVERTER. Select a system suitable for your application.
23.2 Connection Cable . . . . . . . . . . . . page 23-9
This section describes the specifications of the cables
needed when connecting a GOT to a FREQOL SERIES
INVERTER. Check the specifications of the connection
cables.
23.3 Preparatory Procedures for Monitoring . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . page 23-15
This section provides the procedures to be followed before
performing monitoring in connection to a FREQOL SERIES
INVERTER. The procedures are written on the step-by-
step basis so that even a novice GOT user can follow them
to start communications.
23.4 FREQROL Series Inverter Side Settings . .
. . . . . . . . . . . . . . . . . . . . . . . . . page 23-29
The FREQOL SERIES INVERTER side settings for GOT
connection are explained. When checking the PLC side
settings, refer to this section.
23.5 Precautions . . . . . . . . . . . . . . . page 23-31
This section describes the precautions about FREQROL
SERIES INVERTER connection. Refer to this section
without fail before starting servo FREQROL SERIES
INVERTER.
23.6 List of Functions Added by Version Upgrade
. . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . page 23-32
This section describes the functions added by version
upgrade of GT Designer2 or OS.
To Next Page
