24 - 1
24
17
CONNECTION TO
ALLEN-BRADLEY PLC
18
CONNECTION TO
SIEMENS PLC
19
MICROCOMPUTER
CONNECTION
20
CONNECTION TO OMRON
TEMPERATURE
CONTROLLER
21
CONNECTION TO
YAMATAKE TEMPERATURE
CONTROLLER
22
CONNECTION TO RKC
TEMPERATURE
CONTROLLER
23
CONNECTION TO
FREQROL SERIES
INVERTER
24
SERVO AMPLIFIER
CONNECTION
SERVO AMPLIFIER
CONNECTION
24.1 System Configuration . . . . . . . . . page 24-2
This section describes devices and cables needed for
servo amplifier connection.
Refer to this section to select the desired system.
24.2 Connection Cable . . . . . . . . . . . . page 24-9
This section describes the specifications of the cables
needed for servo amplifier connection.
Refer to this section to check the specifications of the
connection cable to be used.
24.3 Preparatory Procedures for Monitoring . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . page 24-14
This section describes the preparatory procedures for the
monitoring in the servo amplifier connection.
The sequential checkup procedure will be helpful for those
who communicate through the GOT for the first time.
24.4 Setting on Servo Amplifier Side
. . . . . . . . . . . . . . . . . . . . . . . . . page 24-28
This section describes the servo amplifier setting for
connection with the GOT.
Refer to this section to check the servo amplifier setting.
24.5 Precautions . . . . . . . . . . . . . . . . page 24-33
This section describes the precautions about servo
amplifier connection.
Refer to this section without fail before starting servo
amplifier connection.
24.6 List of Functions Added by Version Upgrade
. . . . . . . . . . . . . . . . . . . . . . . . . page 24-34
This section describes the functions added by version
upgrade of GT Designer2 or OS.
To Next Page
