Mitsubishi GOT2000 Series User Manual

3 - 22
3.7 Video/RGB
POINTPOINTPOINT
Precautions for setting
Incorrect settings may disrupt or stop the video image.
(If this happens, returning the settings to their default values restores normal display.)
This phenomenon depends on the video camera or other device connected.
Use setting values that provide proper display.
Step 7. The image quality (color tone, contrast,
brightness, color intensity) for the
selected channel No. can be changed.
Touching the [Default] button returns to
the default status.
When touching the [Copy CH1] button,
the image quality (color tone, contrast,
brightness, color intensity) for the
selected channel No. is matched with
the image quality settings for Channel
No. 1 ([CH1]).
Step 8. When touching the [Confirm] button, the
setting contents are determined.
Step 9. If you touch the [×] button without
touching the [Confirm] button, the dialog
on the left is displayed.
Step 10. After completing all the items to set, if
you touch the [×] button, the display
returns to the preview screen step1.
Step 11. After completing the settings for all the
items you want to change in the video
display settings, when closing [Video
Display (Preview)] with the [×] button,
the display returns to [Video/RGB
Setting].
Changes
the number
a certain
Changes
the number
to the
Changes
the
number a

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
