8.2 Error Codes and System Alarm List
8 - 11
8
SYSTEM ALARM DISPLAY AND LIST
581 Abnormal Advanced recipe file
Recipe cannot be executed for recipe file with incorrect contents. Delete the recipe
file from the SD card or USB memory.
582
Cannot generate Advanced recipe
file.
Cannot generate recipe file. Confirm the following and execute recipe processing
again.
• Confirm whether the SD card or USB memory is installed.
• Close the SD card cover to make the SD card accessable.
• Confirm the available memory of the SD card or USB memory.
583
Unable to save device value to
Advanced recipe file.
Unable to save device value to recipe file.
• Confirm the write-protection of the SD card or USB memory.
• Confirm whether the attribute of saving file is for reading only.
584 Advance recipe file save error
An error has occurred during the recipe file writing. Do not pull out the SD card or
USB memory while the Recipe is operating.
585 Advanced recipe file upload error
An error has occurred during the recipe file reading.
Do not pull the SD card or USB memory out while the Recipe is operating.
586
Specified Advanced recipe number
does not exist.
The recipe of non-existing number is about to be executed.
Execute recipe of existing number.
587
Specified record number does not
exist.
The advanced record of non-existing number is about to be executed.
Execute record of existing number.
588
Cannot save recipe data to read only
record.
Saving recipe is about to be executed to the record of which recipe device value
cannot be edited.
Make the recipe device value of the record editable with Recipe Setting of GT
Designer3 or specify the record of which recipe device value can be edited.
589
Recipe device save error. Recipe file
does not exist.
Saving recipe is about to be executed to the recipe setting that is set for not using file.
Specify the recipe setting that uses file.
590
Recipe device upload error. Recipe
device value does not exist.
Loading recipe is about to be executed to the record of which recipe device value is
not set.
Specify the record of which recipe device value is set.
591
Advanced Recipe error. Check
recipe data.
The recipe setting is not correct.
Confirm the recipe setting of the project data and download it to the GOT again.
592
The extension specified to the recipe
file is invalid.
Check if the file name is appropriate.
The file name contains invalid characters. For the details, refer to the following.
➠ GT Designer3 (GOT2000) Help
593
The setting of G1P file of the original
diversion is different from the project
data.
The settings of the sourcMatch the settings of the advanced recipe file and those of
the GOT2000 recipe file, or delete an unnecessary advanced recipe file from the
memory card.e advanced recipe file are not matched with those of the GOT2000
recipe file, or incorrect.
595 Logging file error.
Logging file error.The setting of G1P file of the original diversion is different from the
project data.The setting of G1P file of the original diversion is different from the
project data.
When collecting data again, delete logging files and management files.
596
Logging setting does not exist or
setting value error.
Logging setting does not exist or setting value error.
Specify an existing logging setting in the historical trend graph setting and the
historical data list setting.
597
The specified logging ID does not
exist.
Check the logging ID in the historical trend graph setting.
• Specify an existing logging ID in the Logging ID External Control device.
• Select the graph offset function to specify an existing logging ID in the logging
setting
598
The specified logging setting is
incompatible.
• Configure the setting so that the number of logging devices set for the logging ID
exceeds that of data lines on the historical trend graph.
• Configure the setting so that the data type of the logging device set for the logging
ID is the same as that of the device specified in the historical trend graph.
601 Printer unit error.
The printer unit is installed incorrectly. The built-in flash memory of the printer unit is
broken or the guaranteed life has been elapsed.
Check that the printer unit is installed correctly.
When the printer unit has been installed correctly, the built-in flash memory is broken
or the guaranteed life has been elapsed. Replace the printer unit with new one.
602 Video/RGB unit not mounted
Check if the video/RGB input unit is installed.
Check if the GOT used supports video/RGB input.
603 External I/O unit error Check if the external I/O unit is correctly installed.
604 Sound output unit error Check if the sound output unit is correctly installed.
Error
code
Error message Action
Channel
No. storage
To Next Page
