2.10 Controller
(1) Keyword registration, deletion and protection delete
MELSEC-FX
(a) Registration
Register key words.
Step 1. Touching the [Regist] key pop-up displays the keyboard for inputting a keyword.
Step 2. Input a keyword and touch the [Enter] key, and the registration completes.
Up to 8 characters can be set for keyword with using A to F and 0 to 9.
*1 The access restriction can be selected from [Read/Write Protect], [Write Protect], and [All Protect].
For access restriction on each setting, refer to the following manual.
➠ The User's Manual of the FX series PLC you are using
PLC connected
Setting
When registering keyword and 2nd keyword When registering keyword only
FX CPU compatible with
2nd keyword
[Registration condition]
*1
can be selected.
[Registration condition]
*1
cannot be selected.
FX CPU not compatible
with 2nd keyword
-
To Next Page
