7 APPLICATION INSTRUCTION
7.14 Pulse related instruction
535
7
• Specify the ON time by (s1) and the period by (s2) so that [(s2)-(s1)] is equal to or larger than 3 s.
• When a negative value is specified for the ON time by (s1) and the period by (s2), an operation error occurs. (In 16-bit
instruction PWM, no error occurs.)
• Specify 2 s or more in Y0 to Y3 and 200 s or more in Y4 to Y7 for the ON time specified by (s1), and specify 5 s or more
in Y0 to Y3 and 400 s or more in Y4 to Y7 for the period specified by (s2).
• When a channel number that is not selected for the PMW output in the parameter setting is specified for (d), this instruction
is not executed. An operation error occurs.
• Operations when the PMW output is stopped (while the output pulse is on)
Period
Output stop command
If an output stop command is issued while the ON
time setting is 5 s or less, outputting pulses
stops after the set ON time elapses.
When the ON time setting is 5s or more and 5 s or
less time has elapsed when an output stop command is
issued, outputting pulses stops in 5 s from the stop
command.
ON time
setting is 5 s
or less
ON time
setting is 5 s
or more
ON time
setting is 5 s
or more
ON time
setting is 5 s
or more
ON time
setting is 5 s
or more
ON time
setting is 5 s
or less
5 s
or less
Output stop command is issued
within 5 s of the ON width time.
5 s or
more
Output stop command is issued in
5 s or more of the ON width time.
When the ON time setting is 5 s or more and 5 s or
more time has elapsed when an output stop command is
issued, outputting pulses stops with the stop command.
Period
Period
