564
7 APPLICATION INSTRUCTION
7.17 Data operation instruction
• Do not change the contents of operands and data during operation.
• To execute these instructions again, set the command input to off once, then on again.
• These instructions can be used up to twice in any program.
• When specifying the same device in (s) and (d), the source data is overwritten by the data acquired by sorting. Take special
care so that the contents of (s) are not changed until execution is completed.
• Ensure that the sorted data does not overlap with the source data.
Error code
(SD0/SD8067)
Description
2820 The device range specified by (s) exceeds the corresponding device range.
The device range specified by (d) exceeds the corresponding device range.
3405 The value specified by (m1) is outside the following range.
1 to 32
The value specified by (m2) is outside the following range.
1 to 6
The value specified by (n) is outside the following range.
1 to (m2)
D10 D30
D2 D22
D10 D30
D20 D40
D10 D30
D10 D30
D10 D30
D35 D55
D50 D70
D20
D40
Source Data
Sorted Data
Source Data
Sorted Data
Source Data
Sorted Data
Source Data
Sorted Data
Source Data
Sorted Data
To Next Page
