11 POSITIONING INSTRUCTION
11.1 Positioning Instruction
DRVI [For the FX5 Series operand specification]
This instruction executes one-speed positioning by incremental drive.
■Descriptions, ranges, and data types
■Applicable devices
*1 T, ST, C cannot be used.
This instruction executes one-speed positioning by incremental drive. Specify the positioning address in the incremental
system, in which the transfer direction and transfer distance from the current position (relative address) are specified for
positioning.
• For (s1), specify the relative positioning address in user units. (The address must be within the range of -2147483647 to
+2147483647 number of pulses.)
• For (s2), specify the command speed in user units. (The speed must be 200 Kpps or lower in frequency.)
• For (d1), specify the axis number from which pulses are output.
• For (d2), specify the bit device of the normal complete flag or abnormal end flag for the DRVI instruction.
For details on the function and error code, refer to Built-in positioning manual.
Two devices are occupied from the device specified in (d2). Make sure that these devices are not used in other controls.
For other precautions, refer to Built-in positioning manual.
Ladder diagram Structured text
ENO:=DRVI(EN,s1,s2,d1,d2);
Operand Description Range Data type Data type (label)
(s1) Positioning address -32768 to +32767 16-bit signed binary ANY16
(s2) Command speed 1 to 65535 16-bit unsigned binary ANY16
(d1) Axis number from which pulses are to be output K1 to 4 16-bit signed binary ANY_ELEMENTARY
(d2) Bit device number of the positioning complete flag or abnormal end flag Bit ANY_BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB
U\G T, ST,
C, LC
T, ST, C, D,
W, SD, SW, R
U\G Z LC LZ K, H E $
(s1)
(s2)
(d1)
(d2)
*1
