70
2 CPU MODULE INSTRUCTION
2.3 Application instruction
â– Dead band control of 16-bit/32-bit binary data
â– Zone control of 16-bit/32-bit binary data
â– Scaling 16-bit/32-bit binary data (point coordinates)
â– Scaling 16-bit/32-bit binary data (XY coordinates)
Instruction symbol Description Reference
BAND When (s1) ï‚£ (s3) ï‚£ (s2): 0 ï‚® (d)
When (s3) < (s1): (s3) - (s1) ï‚® (d)
When (s2) < (s3): (s3) - (s2) ï‚® (d)
Page 476
BANDP
BAND_U
BANDP_U
DBAND When [(s1)+1, (s1)] ï‚£ [(s3)+1, (s3)] ï‚£ [(s2)+1, (s2)]: 0 ï‚® (d+1, d)
When [(s3)+1, (s3)] < [(s1)+1, (s1)]: [(s3)+1, (s3)] - [(s1)+1, (s1)] ï‚® [(d)+1, (d)]
When [(s2)+1, (s2)] < [(s3)+1, (s3)]: [(s3)+1, (s3)] - [(s2)+1, (s2)] ï‚® [(d)+1, (d)]
Page 478
DBANDP
DBAND_U
DBANDP_U
Instruction symbol Description Reference
ZONE When (s3) = 0: 0 ï‚® (d)
When (s3) > 0: (s3) + (s2) ï‚® (d)
When (s3) < 0: (s3) + (s1) ï‚® (d)
Page 480
ZONEP
ZONE_U
ZONEP_U
DZONE When [(s3)+1, (s3)] = 0: 0 ï‚® [(d)+1, (d)]
When [(s3)+1, (s3)] > 0: [(s3)+1, (s3)] + [(s2)+1, (s2)] ï‚® [(d)+1, (d)]
When [(s3)+1, (s3)] < 0: [(s3)+1, (s3)] + [(s1)+1, (s1)] ï‚® [(d)+1, (d)]
Page 482
DZONEP
DZONE_U
DZONEP_U
Instruction symbol Description Reference
SCL Executes scaling using the scaling conversion data (16-bit data units) specified by (s2) for the input
value specified by (s1), and then stores the result in the device specified by (d).
The scaling conversion is executed based on the scaling conversion data stored in the device
specified by (s2) onwards.
Page 484
SCLP
SCL_U
SCLP_U
DSCL Executes scaling using the scaling conversion data (32-bit data units) specified by (s2) for the input
value specified by (s1), and then stores the result in the device specified by (d).
The scaling conversion is executed based on the scaling conversion data stored in the device
specified by (s2) onwards.
Page 487
DSCLP
DSCL_U
DSCLP_U
Instruction symbol Description Reference
SCL2 Executes scaling using the scaling conversion data (16-bit data units) specified by (s2) for the input
value specified by (s1), and then stores the result in the device specified by (d).
The scaling conversion is executed based on the scaling conversion data stored in the device
specified by (s2) onwards.
Page 490
SCL2P
SCL2_U
SCL2P_U
DSCL2 Executes scaling using the scaling conversion data (32-bit data units) specified by (s2) for the input
value specified by (s1), and then stores the result in the device specified by (d).
The scaling conversion is executed based on the scaling conversion data stored in the device
specified by (s2) onwards.
Page 493
DSCL2P
DSCL2_U
DSCL2P_U
