Motorola MC909X - Page 39

Getting Started 1 - 15
Figure 1-8 Removing SIM Door
3. Unlock the SIM holder by sliding the metal clip to the open position.
4. Lift the SIM holder.
Figure 1-9 Unlock SIM Case
5. Insert the SIM card, as shown in Figure 1-10, with the cut edge of the card facing the top of the mobile
computer and the contacts facing down.
6. Lower the SIM holder.
Figure 1-10 Inserting the SIM Card
7. Lock the metal clip by sliding it to the closed position.
SIM
Door
SIM Holder
