2 - 42 MC909X Integrator Guide
Table 2-11
S-Register Settings
Reg Function Range
Default
Units
Default Saved
S0 Rings to Auto Answer 0-255 0 * rings
S1 Ring Counter 0-255 0 * rings
S2 Escape Character 0-255 43 ASCII
S3 Carriage Return Character 0-127 13 ASCII
S4 Line Feed Character 0-127 10 ASCII
S5 Backspace Character 0-255 8 ASCII
S6 Wait Time before Blind Dialing or Dial Tone 2-255 2 * S
S7 Wait Time for Carrier, Silence or Dial Tone 1-255 50 * S
S8 Pause Time for Dial Delay Modifier 0-255 2 * S
S9 Carrier Detect Response Time 1-255 6 * 0.1 S
S10 Lost Carrier to Hangup Delay 1-255 14 * 0.1 S
S11 DTMF Tone Duration 50-255 95 * mS
S12 Escape Prompt Delay (EPD) 0-255 50 * .02 S
S14 General Bit Mapped Options Status - 138 (8Ah)
S16 Test Mode Bit Mapped Options Status - 0
S19 Reserved - 0
S20 Reserved - 0
S21 V.24 Bit Mapped Options Status - 52 (34h)
S22 Speaker/Results Bit Mapped Options - 117 (75h)
S23 General Bit Mapped Options Status - 62 (3Dh)
S24 Sleep Inactivity Timer 0-255 0 S
S25 Delay to DTR off 0-255 5 S
S26 RTS-to-CTS Delay 0-255 1 .01 S
S27 General Bit Mapped Options Status - 73 (49h)
S28 General Bit Mapped Options Status - 0
S29 Flash Dial Modifier Time 0-255 70 10 mS
S30 Disconnect Inactivity Timer 0-255 0 10 S
* Register value may be stored in on of two user
** Country-dependent
