VJ-1604　 Maintenance Manual 9 Troubleshooting
9-59 Rev.-05
17 Poor accuracy of
segment length in
media feed direction
(sub scan direction)
1. Is working
environment
appropriate?
Use machine under specified
environment.
"3.5
Choosing a
Place for the
Printer" p.3-6
2. Is PF driving pulley
loose?
Replace PF motor assembly. "4.6.2
Replacing PF
Motor
Assembly"
p.4-62
3. Is PF belt tension
adjusted to
specification?
Adjust PF speed reduction
belt tension.
"(3)
Confirming
Completion of
Installation to
Plotter" p.7-20
4. Does pressure roller
drag when pressure
lever is raised?
If pressure roller collects
media dust on itself, wipe
dust away using a wet soft
cloth.
Operation
Manual
5. Is rough surface of grid
roller partially worn
out?
6. Is grid roller rotation
heavy? Does rattling
occur when it rotates?
If grid roller is contaminated
with media dust, clean roller
with a nylon brush.
Operation
Manual
7. If the media in
problem is roll media,
does scroller rotate
evenly?
Adjust roll receiver assembly
position.
Replace roll receiver
assembly.
Change media to be used.
"4.12.1
Replacing Roll
Media Holder
Assembly on
the VJ16_L
Side" p.4-149
"4.12.2
Replacing Roll
Media Holder
Assembly on
the VJ16_R
Side" p.4-150
Table 9-9 Symptoms, Check Items and Actions for Printing Problems (Continued)
No. Symptom Check item Action Reference
To Next Page
