About this Manual VJ-1604 Maintenance Manual
(3)
About this Manual
1. Purpose and Target Readers
This manual explains preparations needed before maintaining and checking operations for MUTOH Full
Color Ink Jet Printer (VJ-1604A/VJ-1604E/VJ1604J/VJ-1604K2).
This manual is prepared for the maintenance personnel of this printer.
Before using this printer, fully understand the contents and directions in this manual.
2. Manual Configuration
Section Contents
1 Safety Instructions Explains types of warnings, cautions and warnings labeled on the printer
for the both operators of the printer and maintenance personnel.
2 Product Overview Explains the features, part names, and functions of the printer.
3 Specifications Explains the specifications of the printer.
4 Parts Replacement Explains the procedures of replacement and removal of the service parts
of the printer.
5 Self-Diagnostic Mode Explains the self-diagnostic functions of the printer.
6 Maintenance Mode Explains the maintenance mode of the printer.
7 Adjustment Explains the adjusting procedures of the printer parts.
8 Maintenance Explains daily maintenance of the printer.
9 Troubleshooting Explains troubles that may occur when using the printer and how to
solve them.
10 Appendix Explains the maintenance information and the exploded views for this
printer.
Use the built-in self-diagnostic program to locate a defective part and adjust/
check during maintenance.
