Navistar ProStar+

To Next Page

To Previous Page

Operation

WarningsofSCRSystemFault(ForVehiclesEquippedwithCummins

ISX15Engines)

LevelIndicationAudibleAlarmVehicleConditions/Operation

1Beep

InitialWarning–faultcodehas

beenset.

1Beep

Engineperformanceisderatedby

atleast25%.

1Beep

Engineperformanceis

progressivelyderatedbyup

to40%.

175
