Operation

WarningsofSCRSystemFault(ForVehiclesEquippedwithCummins

ISX15Engines)(cont.)

LevelIndicationAudibleAlarmVehicleConditions/Operation

and

1Beep

Engineperformanceisderatedby

40%.Vehiclespeedislimitedto

5mph(8km/h).

176
