Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-64 P/N 196515 (Revision A)
Locate the SERVO MOTOR
LEDs on the XY Servo
Interface PWA.
Observing the LEDs,
determine status of Servo
Amplifier using the following
table.
Function AOK SO1 SO2 SO3 Action
Amplifier OK Off Off Off Off No Servo Amplifier fault
External Disable Off On Off On Go to External Disable Check
Current Limit Off Off Off On Contact Asymtek Technical Support*
Short On On Off On Contact Asymtek Technical Support*
Over temperature On Off On On Contact Asymtek Technical Support*
Internal Supplies On On On Off Contact Asymtek Technical Support*
Under Voltage On On Off Off Contact Asymtek Technical Support*
Over Voltage On Off On Off Contact Asymtek Technical Support*
Shunt Request Off Off On Off Contact Asymtek Technical Support*
Power Up Reset On Off Off Off Go to Power Up Reset Check
Commutation Failure On On On On Contact Asymtek Technical Support*
*Servo Amplifier may be damaged
Switch Main Circuit Breaker
to ON (I) position and press
green ON (I) button on the
Operator’s Console.
Locate the SERVO MOTOR
LEDs on the XY Servo
Interface PWA.
Observing the LEDs,
determine status of Servo
Amplifier using the following
table.
Function AOK SO1 SO2 SO3 Action
Amplifier OK Off Off Off Off No Servo Amplifier fault
External Disable Off On Off On Go to External Disable Check
Current Limit Off Off Off On Contact Asymtek Technical Support*
Short On On Off On Contact Asymtek Technical Support*
Over temperature On Off On On Contact Asymtek Technical Support*
Internal Supplies On On On Off Contact Asymtek Technical Support*
Under Voltage On On Off Off Contact Asymtek Technical Support*
Over Voltage On Off On Off Contact Asymtek Technical Support*
Shunt Request Off Off On Off Contact Asymtek Technical Support*
Power Up Reset On Off Off Off Go to Power Up Reset Check
Commutation Failure On On On On Contact Asymtek Technical Support*
Function AOK SO1 SO2 SO3 Action
Amplifier OK Off Off Off Off No Servo Amplifier fault
External Disable Off On Off On Go to External Disable Check
Current Limit Off Off Off On Contact Asymtek Technical Support*
Short On On Off On Contact Asymtek Technical Support*
Over temperature On Off On On Contact Asymtek Technical Support*
Internal Supplies On On On Off Contact Asymtek Technical Support*
Under Voltage On On Off Off Contact Asymtek Technical Support*
Over Voltage On Off On Off Contact Asymtek Technical Support*
Shunt Request Off Off On Off Contact Asymtek Technical Support*
Power Up Reset On Off Off Off Go to Power Up Reset Check
Commutation Failure On On On On Contact Asymtek Technical Support*
FunctionFunctionFunction AOKAOKAOK SO1SO1SO1 SO2SO2SO2 SO3SO3SO3 ActionActionAction
Amplifier OKAmplifier OK OffOff OffOff OffOff OffOff No Servo Amplifier faultNo Servo Amplifier fault
External DisableExternal Disable OffOff OnOn OffOff OnOn Go to External Disable CheckGo to External Disable Check
Current LimitCurrent Limit OffOff OffOff OffOff OnOn Contact Asymtek Technical Support*Contact Asymtek Technical Support*
ShortShort OnOn OnOn OffOff OnOn Contact Asymtek Technical Support*Contact Asymtek Technical Support*
Over temperatureOver temperature OnOn OffOff OnOn OnOn Contact Asymtek Technical Support*Contact Asymtek Technical Support*
Internal SuppliesInternal Supplies OnOn OnOn OnOn OffOff Contact Asymtek Technical Support*Contact Asymtek Technical Support*
Under VoltageUnder Voltage OnOn OnOn OffOff OffOff Contact Asymtek Technical Support*Contact Asymtek Technical Support*
Over VoltageOver Voltage OnOn OffOff OnOn OffOff Contact Asymtek Technical Support*Contact Asymtek Technical Support*
Shunt RequestShunt Request OffOff OffOff OnOn OffOff Contact Asymtek Technical Support*Contact Asymtek Technical Support*
Power Up ResetPower Up Reset OnOn OffOff OffOff OffOff Go to Power Up Reset CheckGo to Power Up Reset Check
Commutation FailureCommutation Failure OnOn OnOn OnOn OnOn Contact Asymtek Technical Support*Contact Asymtek Technical Support*
*Servo Amplifier may be damaged
Switch Main Circuit Breaker
to ON (I) position and press
green ON (I) button on the
Operator’s Console.
Diagram Sheet 4-5-8
Z Servo Amplifier Fault Isolation Procedure - Servo Amplifier Verification
