Nordson Asymtek X-1000 Series User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-107 P/N 196515 (Revision A)
A
Exit FmNT, shut down Windows
NT, press the black OFF (0)
button on the Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from the facility outlet.
Check continuity (Pinout is 1 to 1)
of Stepper Motors Cable
(Conveyor Controller to the
Conveyor Interconnect PWA).
Is there continuity?
Conveyor Controller
(P/N 62-1677-00 on
X1020, or P/N 62-1676
on X1010) has failed
Stepper Motors Cable
(P/N 06-4612-00) has
failed
B
Check continuity (Pinout is 1 to 1)
of Belt Motor Cable (Interconnect
PWA to Motors).
Is there continuity?
Belt Motor (P/N 07-0716-
00) has failed
Belt Motor Cable (P/N 06-
4622-00) has failed
Yes No
Yes No
A
Exit FmNT, shut down Windows
NT, press the black OFF (0)
button on the Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from the facility outlet.
Check continuity (Pinout is 1 to 1)
of Stepper Motors Cable
(Conveyor Controller to the
Conveyor Interconnect PWA).
Is there continuity?Is there continuity?
Conveyor Controller
(P/N 62-1677-00 on
X1020, or P/N 62-1676
on X1010) has failed
Stepper Motors Cable
(P/N 06-4612-00) has
failed
B
Check continuity (Pinout is 1 to 1)
of Belt Motor Cable (Interconnect
PWA to Motors).
Is there continuity?Is there continuity?
Belt Motor (P/N 07-0716-
00) has failed
Belt Motor Cable (P/N 06-
4622-00) has failed
Yes No
Yes No
Diagram Sheet 4-8-8
Conveyor Motors Fault Isolation Procedure – Rear/Front Belt Motor Verification (Continued)
