Component - function table
#
Description / FunctionComponentNo.
Switch the main power supply on or off.
You can find the serial number of the
printer on the sticker above the power
switch.
power switch1
Open the upper back cover with the media
jam clearance handle when you want to
access the heater section in case of a media
jam.
upper back cover2
Use this handle to access the paper in case
of a paper jam in the heater section.
media jam clearance handle3
Chapter 2 - Get to Know the Printing System 29
The components of the printer (back)
