The components of the scanner (optional)
Note:
The scanner calibration sheet for the 'Océ Scanner Express' is located in the media
drawer at the back of roll 2.
Illustration
[20] The integrated scanner.
The components of the scanner
#
Description / FunctionComponent
Closes off the scanner.scanner top cover1
Use the original feeding table to feed the
original into the scanner (face up).
original feeding table2
Use the scanner open levers to open the
scanner top cover.
scanner open levers3
Exit for the scanned original.originals exit4
Prevents your output from being refed into
the scanner.
Output refeed protector5
Chapter 2 - Get to Know the Printing System 35
The components of the scanner (optional)
