Component - function table
#
Description / FunctionComponentNo.
Carries the media rollroll holder1
Media placed on roll holder in first position.media roll 12
Media placed on roll holder in second position.
Note:
The scanner calibration sheet is located at
the back of roll 2.
media roll 2 (optional)3
Groove integrated behind the front cover of the
media drawer, on which the media can be easily
loaded.
roll loading station4
Button used to trim a strip of a new or damaged
media roll.
clean cut button5
Chapter 2 - Get to Know the Printing System30
The media drawer
