Océ PlotWave 340 - Load a Media Roll (Position

Slide (2) the roll holder into the right side of the core of the new media roll.
1
2
4.
Align the roll with the center of the correct size indicator on the roll holder and release
the handle of the locking mechanism.
Note:
If you use a B1 media size, (707 mm) you must align the media roll with the A1 indent.
Chapter 5 - Maintain the Printing System 311
Load a media roll (position 2)
Operating Information: PlotWave (PW) 340, PW350 - Edition 2013-06
