Load a media roll (position 2)
Note:
When your printing system is equipped with an additional second media roll, it is advised
to load an A0 or E-size media roll on position 1 and an A2 or C-size media roll on posi-
tion 2.
Caution:
Watch your fingers when you handle the media roll.
Caution:
If you want to load an A0 media roll on position 2,make sure to bend your knees, as in-
dicated below, to spare your back.
How to load a media roll on position 2
1.
Pull firmly to open the media drawer.
2.
Place the new media roll on the roll loading station.
3.
Pull (1) the handle of the roll holder locking mechanism toward you.
Chapter 5 - Maintain the Printing System310
Load a media roll (position 2)
